Extron electronics CrossPoint 450 Plus Series User Manual

Operation, cont’d
CrossPoint / MAV Matrix Switchers • Operation
3-4
Input and output buttons
Primary functions
Action:
Select input or output for tie being created.
Indications:
Blink: potential tie/untie
Lit: current tie
Amber: video and audio tie
Green: video only tie
Red: audio only tie
1
2
3
through up to
32
Secondary functions
I/O Grouping Action 1:
Input 1 and Output 1:
Select I/O Group
mode.
Action 2/
indication:
Assign an input or output to the selected group.
Lit: Input or output is assigned to the selected group.
Presets Action/
indication:
Select a preset in Preset mode.
Lit: A preset has already been saved to this location.
Blink: Preset location is selected to be saved.
RGB Delay Indication:
CrossPoint:
Input 1 through 10: Indicate the RGB delay.
Input audio
level
Action/
indication:
(inputs)
Inputs: Select the input’s audio for gain or attenuation adjustment.
Lit: Input’s audio is selected for adjustment.
Indication:
(outputs)
Indicate the input gain or attenuation level.
Output audio
volume
Action/
indication:
(outputs)
Outputs: Select the output’s audio for volume adjustment.
Lit: Output’s audio is selected for adjustment.
Indication:
(inputs)
Indicate the output volume level.
Mutes Action/
indication:
Outputs: Press and hold to mute the video and audio, video, or audio output.
Outputs, blink: Output is muted.
Background
illumination
Action:
Toggle between background illumination
or buttons unlit.
N
If the switcher has fewer inputs or outputs than input or output buttons,
only the buttons for which the switcher has an input or an output perform the
function of selecting and identifying that input or output.
