CrossPoint / MAV Matrix Switchers • HTML Operation
Change the output volume level (audio models)
Userscanseteachoutput’svolumelevelthrougharangeofzerostepsof
attenuation(fullattenuation,minimumvolume)to64stepsofattenuation(no
attenuation,fullvolume)fromtheRGBandAudioSettingspage.
Change an output’s audio level setting as follows:
1
. Clicktheoutputdropbox.Adropdownscrollboxappears(gure6-18).
Figure 6-18 — Output selection drop box
2. Click and drag the slider or click the scroll up button or scroll down
button until the desired output is visible.
3
. Click the desired output.
4. ClicktheVolumeSteps(64Max)dropbox.Adropdownscrollboxappears
(gure6-19).
Figure 6-19 — Volume drop box
5. Click the desired output volume step value.
N
The table on the next page defines the value of each audio volume step.
