Extron electronics CrossPoint 450 Plus Series User Manual

HTML Operation, cont’d
CrossPoint / MAV Matrix Switchers • HTML Operation
6-16
Change the RGB delay (CrossPoint switchers)
The RGB delay interval defines how long the screen is blanked when switching to a
new input for the selected output.
Change the RGB delay as follows:
1
. ClicktheOutputdropbox.Adropdownscrollboxappears(gure6-16).
Figure 6-16 — Output selection drop box
2. Click and drag the slider or click on the scroll up button or scroll down
button until the desired output is visible.
3
. Click the desired output.
4. ClicktheRGBdelaydropbox.Adropdownscrollboxappears(gure6-17).
Figure 6-17 — RGB delay drop box
5. Click the desired RGB delay.
