Extron electronics CrossPoint 450 Plus Series User Manual

4-7
CrossPoint / MAV Matrix Switchers • Programmer’s Guide
Amtnn•x
]
TheswitcherinitiatestheAmtmessagewhenanaudioorRS-232outputmuteis
toggled on or off from the front panel. nnistheoutputnumber,•isaspace,andx
isthemutestatus:1=on,0=off.
Exen
]
The switcher initiates the Exe message when executive mode is toggled on or off
from the front panel. nistheexecutivemode:0,1,or2.
Switcher Error Responses
WhentheswitcherreceivesanSIScommandanddeterminesthatitisvalid,it
performsthecommandandsendsaresponsetothehostdevice.Iftheswitcher
is unable to perform the command because the command is invalid or contains
invalid parameters, the switcher returns an error response to the host. The error
response codes are:
 E01—Invalidinputchannelnumber(toolarge)
 E10—Invalidcommand
 E11—Invalidpresetnumber
 E12—Invalidoutputnumber(toolarge)
 E13—Invalidvalue(outofrange)
 E14—Illegalcommandforthisconguration
 E17—Timeout(causedonlybydirectwriteofglobalpresets)
 E21—Invalidroomnumber
E22 — Busy
 E24—Privilegeviolation(Usershaveaccesstoallviewandread
commands (other than the Adminstrator password), and can
create ties, presets, and video and audio mutes
 E25—Devicenotpresent
 E26—Maximumnumberofconnectionsexceeded
 E27—Invalideventnumber
 E28—Badlename/lenotfound
Using the Command/Response Tables
Thecommand/responsetablesbeginonpage4-9.Lower-caselettersareacceptable
in the command field except where indicated for the gain and attenuation
commands.ThetablebelowshowsthehexadecimalequivalentofeachASCII
characterusedinthecommand/responsetable.
ASCII to HEX Conversion Ta ble
Space
