CrossPoint / MAV Matrix Switchers • HTML Operation
6-14
Change the input gain and attenuation (audio models)
Userscanseteachinput’slevelofaudiogainorattenuation(-18dBto+24dB)from
theRGBandAudioSettingspage.Audiolevelscanbeadjustedsothereareno
noticeable volume differences between sources.
Change an input’s audio level setting as follows:
1
. ClicktheInputdropbox.Adropdownscrollboxappears(gure6-12).
Figure 6-12 — Input selection drop box
2. Click and drag the slider or click on the scroll up button or scroll down
button until the desired input is visible.
3
. Click the desired input.
4. ClicktheInputAudioLevel(dB)dropbox.Adropdownscrollboxappears
(gure6-13).
Figure 6-13 — Gain drop box
5. Click and drag the slider or click on the scroll up button or scroll down
button until the desired input is visible.
6
. Click the desired gain or attenuation value.
