4-21
CrossPoint / MAV Matrix Switchers • Programmer’s Guide
Command/Response Table for IP-specific SIS Commands
Symbol definitions
X3)
= Matrixname (Upto240alphanumericcharacters)
N
The following characters are invalid in the name: {space} ~ , @ = ` [ ] { } < > ‘ “ ; : | \ and ?.
X3!
= Defaultname Factorydefaultname(modelname +last3pairsofMACaddress)
X3@
= Timeanddate(forset) IntheformatMM/DD/YY•HH:MM:SS, where:
MM=month:01(January)through12(December)
DD=01through31
YY=00through99
HH=00through23
MM=00through59
SS=00through59
X3#
= Timeanddate(forread) IntheformatDay,•DD•Mmm•YYYY•HH:MM:SS, where:
Day=weekday:MonthroughSun
DD=01through31
Mmm=month:JanthroughDec
YYYY=2000through2099
HH=00through23
MM=00through59
SS=00through59
X3$
= GMToffset –12.0through+14.0.HoursandminutesremovedfromGMT
X3%
= DaylightSavingTime 0=DaylightSavingTimeoff/ignore
1=DaylightSavingTimeon(northernhemisphere)
2=DaylightSavingTimeon(Europe)
3=DaylightSavingTimeon(Brazil)
X3^
= IPaddress ###.###.###.###
X3&
= Hardware(MAC)address ##-##-##-##-##-##
X3*
= Numberofopenconnections 0-255
X3(
= Password 12alphanumericcharacters
N
The following characters are invalid in passwords: {space} + ~ , @ = ` [ ] { } < > ‘ “ ; : | \ and ?.
X4)
= Domainname Standarddomainnamerulesapply(forexample:nnnnn@xxx.com)
N
The following characters are invalid in a domain name: {space} + ~ , = ` [ ] { } < > ‘ “ ; : | \ and ?. The @ character is acceptable only as
the lead-in to the domain name (such as @extron.com).
X4!
= E-mailaccount 65-72.65=e-mailrecipient1,66=2,67=3,...72=recipient#8
X4@
= E-mailaddress Typicale-mailaddressformat(forexample:nnnn@xxx.com)
X4#
= Notifywhen? 0=noresponse 3=both1&2
1=fail/missing 4=suspend
2=xed/restored
X4$
= Noticationselections Matrixsize2412andlarger: 01-32=input1throughinput32
98=powersupplies
99=fans
Matrixsize1616andsmaller: 01-17=input1throughinput16
17=powersupply
X4%
= Notifystatus(forread) 34-or17-digitnumber.Foreachdigit:0=donotnotify,1=notify
X4^
= DHCP 0=1off,1=on
X4&
= Port# 00through99(00=allports)
X4*
= Baudrate 9600,19200,38400,115200
X4(
= Parity odd, even, none, mark, space (only the first letter required)
X5)
= Databits 7,8
X5!
= Stopbits 1,2
X5@
= Porttype 0=RS-232
1=RS-422
2=RS-485
