Matrix Software, cont’d
CrossPoint / MAV Matrix Switchers • Matrix Software
5-4
Using the Matrix Switcher Control software
ManyitemsfoundintheMatrixSwitchersControlProgramarealsoaccessible
viafrontpanelcontrols(seechapter3,”Operation”)andunderSIScontrol(see
chapter4,“Programmer’sGuide”).TheMatrixSwitcherHelpProgramprovides
information on settings and on how to use the control program, itself.
1.
 ToruntheMatrixSwitchersControlProgram,clickStart>
Programs>Extron Electronics>Matrix Switchers>
MATRIX Switcher + Control Pgm.
 TheCommPortSelectionwindow(gure5-3)appears.
Figure 5-3 — Comm port selection window
2. ChoosethecommportthatisconnectedtotheCrossPointorMAVswitcher’s
rearpanelRS-232/RS-422portortothefrontpanelCongport(matrixsizes
upto1616),IP [LAN], or Emulate.
If you selected a comm port, check the baud rate
displayedintheBaudRateeld.Ifyouneedto
change the baud rate, click on the Baud button and
double-click on the desired baud rate.
 Availableratesare9600,19200,38400,and115200.The
defaultis9600.
Click OK and proceed to step 4.
• If you selected IP [LAN], click OK and proceed to step 3.
• If you selected Emulate, click OK
andsee“UsingEmulationmode”on
page 5-22.
3
. If you selected IP [LAN] in step 2,theIPConnectionwindowappears
(gure5-4).
Figure 5-4 — Address and password entry
