341
www.factoryfive.com 508-291-3443
Side body mounts
Drill,
5
/
16
” drill bit,
3
/
16
” hex key, ½” wrench, marker, ruler.
Secondary body fasteners
The body sides are mounted using four stainless
5
/
16
”x 1” bolts with a washer next to the head.
The rear most side body mount needs
7
/
16
” worth of washers between the body and the frame so that the
body is spaced correctly and there is enough thread left so the locking part of the nut is used.
When you are fitting the doors the number of washers may have to be changed to ensure a flush door fit.
The edge of the body doorsill should be flush with the inside side of the doorsill 1”x 1” tube. Use a #6
self-tapping screw to hold it in place if necessary.
Work from the rear of the car towards the front.
