Factory Five Racing Type 65 Coupe - Front Suspension Torque Specs Chart; IFS Bracket

71
www.factoryfive.com 508-291-3443
Front Suspension Torque Specs Chart
Item Nm Lbft
Front lower control arm to frame 135-162 100-110
Front lower ball joint to spindle 106-163 80-120
Upper A-arm to frame 135-162 100-110
Upper ball joint to Spindle 95-122 70-90
Spindle hub nut 305-338 225-250
IFS Bracket
 IFS components, Mustang strut bolts
 These are not used in the complete Coupe kit
Attach the Spindle adapter bracket to the upper control arm to the spindle using the factory strut bolts
and torque to 135-149Nm (100-110 lbft).
 Using the 87-93 spindles, use the hole closest to the ball joint and the third hole down. Using a
94-04 Spindles, attach the bracket using the bottom and third hole up so that the ball joint is
further away from the spindle.
