407
www.factoryfive.com 508-291-3443
JI
A
COUPE TAIL LIGHT TEMPLATE
USE A LEVEL ON THIS LINE
7.50" TO OUTER EDGE OF BODY
7.375" TO OUTER EDGE OF BODY
W EIGHT:
13022
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FACTORY FIVE RACING, INC. ANY
R EPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FACTORY FIVE RACING, INC. IS
PROHIBITED.
COMMENTS:
S HEET 1 OF 1
Q.A.
MFG APPR.
ENG APPR.
C HECKED
DRAWN
DATENAME
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL 1/32
TWO PLACE DECIMAL 0.05
THREE PLACE DECIMAL 0.01
NEXT ASSY USED ON
APPLICATION
DO NOT SCALE DRAWING
FINISH
MATERIAL
A
DWG. NO.SIZE
SCALE:1:1
1.25
