5. Diagnostics and error handling
5−3
Festo P.BE−CPX−SYS−EN en 0902e
5.1 General notes on diagnosis
The CPX terminal offers extensive possibilities of diagnosis
and error treatment. The following possibilities are available
(see also Tab.5/1):
X1
X2
X3
X4
X1
X2
X3
X4
X1
X2
X3
X4
1
2
3
1
On the spot diagnosis with LED
2 On the spot diagnosis with handheld
3 Diagnosis via the fieldbus
Fig.5/1: Diagnostics options of the CPX terminal
