Festo CPX - System Data: System Start; System Data: Fail Safe

B. Parameters and data of the CPX terminal
B−39
Festo P.BE−CPX−SYS−EN en 0902e
System data: System start
Function no. 0
Description Specifies how the system start of the CPX terminal is to be carried out
Bit Bit 7
Values
Bit 7
0
1
System start
Description
System start with default parametrisation (factory
setting) and current CPX equipment status
System start with saved parametrisation and saved
CPX equipment status
[System start]
[Default parameters]
[Saved parameters]
Note See also system parameter System start."
Tab.B/52: System start
System data: Fail safe
Function no. 1
Description Specifies whether Fail safe is active or inactive.
Bit Bits 0, 1
Values
Bit 10
00
01
11
Fail safe
Description
Reset all outputs
Hold last state (retain signal status)
Assume fault mode
[Fail safe]
[Reset outputs]
[Hold last state]
[Assume fault mode]
Tab.B/53: Fail safe
