Festo CPX - Channel Number (CN); Fault Number (FN)

B. Parameters and data of the CPX terminal
B−28
Festo P.BE−CPX−SYS−EN en 0902e
Diagnostic memory parameter: Channel number (CN)
Function no. 3486
Description Channel number for the diagnostic memory filter
Bit 0...7 (1 byte)
Values Channel number (CN)
0...63 Channel number (0 = presetting)
[Channel number CN]
Note Is only effective if an appropriate diagnostic memory filter is active.
Tab.B/31: Channel number (CN)
Diagnostic memory parameter: Fault number (FN)
Function no. 3487
Description Fault number for the diagnostic memory filter
Bit 0...7 (1 byte)
Values Fault number (FN)
0...255 Fault number (0 = presetting)
[Fault number FN]
Note Is only effective if an appropriate diagnostic memory filter is active.
Tab.B/32: Fault number (FN)
