Festo CPX - Revision Code; Serial Number

B. Parameters and data of the CPX terminal
B−43
Festo P.BE−CPX−SYS−EN en 0902e
Module data: Revision code
Function no. 16 + 16m + 13; m = module number (0 ... 47)
Description Specifies the output status of the module.
Bit 0...7
Values Revision code
0...255
[Revision]
Note See type plate
Tab.B/60: Revision code
Module data: Serial number
Function no. 784 + m * 4 + 0 (byte 0)
784 + m * 4 + 1 (byte 1)
784 + m * 4 + 2 (byte 2)
784 + m * 4 + 3 (byte 3); m = module number (0 ... 47)
Description Specifies the series number of the module. In byte 0 one nibble (4 bits) contains
the year and the other nibble contains the month of the series (hexadecimal
coding). Of bytes 1..3 each nibble contains a figure of the series number (BCD
coded
1)
).
1) BCD = binary coded decimal number (see Tab.B/62 for an example)
Tab.B/61: Serial number
