System data: Idle mode
Function no. 1
Description Specifies whether Idle mode is active or inactive.
Bit Bits 2, 3
Values
Bit 32
00
01
11
Idle mode
Description
Reset all outputs
Hold last state (retain signal status)
Assume Idle mode
[Idle mode]
[Reset outputs]
[Hold last state]
[Assume idle mode]
Tab.B/54: Idle mode
System data: Monitoring the CPX terminal
Function no. 2
Description Specifies whether the monitoring of short circuit/overload and undervoltage is
active or inactive.
Bit
0
1
2
3
4
5
6
7
Monitoring
Description
Short circuit/overload in sensor supply (SCS)
Short circuit/overload at the outputs (SCO)
Undervoltage at outputs (V
OUT
)
Undervoltage of valves (V
VAL
)
Short circuit at the valve (SCV)
Reserved
Reserved
Reserved
[Monitor]
[Monitor SCS]
[Monitor SCO]
[Monitor Vout]
[Monitor Vval]
[Monitor SCV]
−
−
−
Values 1 = active
0 = inactive
Note See system parameter Diagnostic monitoring"
Tab.B/55: Monitoring the CPX terminal
