B. Parameters and data of the CPX terminal
B−42
Festo P.BE−CPX−SYS−EN en 0902e
B.2.9 Module data
The following module data is available for identifying
modules:
Function no.
Module data
16 + 16m + 0 Module code
16 + 16m + 13 Revision code
784 + m * 4 + 0
784 + m * 4 + 1
784 + m * 4 + 2
784 + m * 4 + 3
Serial number
m = module number
Tab.B/58: Overview of module data
Module data: Module code
Function no. 16 + 16m + 0; m = module number (0 ... 47)
Description Specifies the module code of the module.
Bit 0...7
Values Module code
0 : Reserved
1 ... 63 : Digital modules
64 ... 79 : Pneumatic interfaces
80 ... 127 : Pneumatic modules
128 ... 152: Analogue modules
153 ... 196: Function or technology modules
197 ... 201: Special modules
202 ... 245: CPX bus node
246 ... 255: Reserved
[Module code]
Note The module codes can be found in the relevant module descriptions.
Tab.B/59: Module code
