Festo CPX - Monitoring the CPX Module

B. Parameters and data of the CPX terminal
B−16
Festo P.BE−CPX−SYS−EN en 0902e
Module parameter: Monitoring of the CPX module
Modules Depending on the monitoring function for modules with digital and analogue
inputs and outputs (see description on the respective module)
Function no. 4828 + m * 64 + 0m = module number (0 ... 47)
Description Monitoring of the possible faults can be activated or deactivated (suppressed)
for each module independently. Active monitoring causes the following. The
fault is:
 Sent to the CPX bus node
 Displayed by the module common error LED.
Bit
0
Monitoring
Description
Short circuit/overload in sensor supply (SCS)
[Monitor]
[Monitor SCS]
1 Short circuit/overload at the outputs (SCO) [Monitor SCO]
2 Under voltage of outputs/valves (V
OUT/VAL
) [Monitor Vout/val]
3 Short circuit at the valve (SCV) [Monitor SCV]
4 Reserved −
5 Reserved −
6 Reserved −
7 Monitoring parametrisation faults [Monitor parameters]
Values 1 = active (presetting)
0 = inactive
[Active]
[Inactive]
Note Monitoring can also be set for the complete CPX terminal (see System parame
ter monitoring").
Tab.B/12: Monitoring the CPX module
For parametrising the Monitoring CP modules" on the
CPX−CP interface see the manual for the CPX−CP interface
type P. BE−CPX−CP−....
