Festo CPX - The Method of Operation of the Diagnostic Memory Filters

C. General information on parametrisation
C−21
Festo P.BE−CPX−SYS−EN en 0902e
Fault end filter
Start: Error
Run/stop
Filter 2
Error number filter
Module/channel filter
0 = Always register
1 = Register up to the defined error number
2 = Register up to the defined error number + module number
3 = Register up to the defined error number + module number +
3 = channel number
4 = Register as from the defined error number
5 = Register as from the defined error number + module number
6 = Register as from the defined error number + module number +
6 = channel number
Run/stop filter 1
The first 40 faults or the last 40 faults
Register end of fault or not
Register defined error number or not
Register only error number of a module/channel
Diagnostic memory
MN = module number, CN = channel number, FN = error number
Fig.C/10: The method of operation of the diagnostic memory filters
