Festo CPX - B.2.8 System Data

B. Parameters and data of the CPX terminal
B−36
Festo P.BE−CPX−SYS−EN en 0902e
Module diagnostic data: Information 3 (reserved)
Function no. 2008 + m * 4 + 3; m = module number (0 ... 47)
Description Reserved
Tab.B/46: Information 3 (reserved)
B.2.8 System data
System data provides information about global system set
tings and system states. System data is lost after Power Off
(non−remanent). The following system data is available:
Function no.
System data
0 CPX operating mode
0 CPX expansion
0 Handheld
0 Force mode
0 System start
1 Fail safe
1 System Idle mode
1)
2 Monitoring the CPX terminal
− Number of input bytes (Rx size)
1)
− Number of output bytes (Tx size)
1)
1) Only relevant for certain fieldbus protocols
Tab.B/47: Overview  System data
