Festo CPX - Bit Number

B. Parameters and data of the CPX terminal
B−44
Festo P.BE−CPX−SYS−EN en 0902e
Function no. Bit number Example
1)
7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0
Nibble Nibble Nibble Nibble
784 + m * 4 + 0 Year 2) Month
3)
0 0 0 1 1 1 0 0
784 + m * 4 + 1 100.000 10.000 0 1 1 0 0 1 0 1
784 + m * 4 + 2 1 000 100 0 1 0 0 0 0 1 1
784 + m * 4 + 3 10 1 0 0 1 0 0 0 0 1
1) Example: Serial number 1C654321
2) 0001 (1) = year 2001; 0010 (2) = year 2002 etc.
3) 0001 (1) = January; 0010 (2) = February ... 1011 (B) = November; 1100 (C) = December
Tab.B/62: Bit number
