Festo CPX - Diagnostic Memory

B. Parameters and data of the CPX terminal
B−23
Festo P.BE−CPX−SYS−EN en 0902e
B.2.4 Diagnostic memory parameters
The working method of the diagnostic memory can be
adapted to individual requirements by means of the diagnos
tic parameters.
The diagnostic memory parameters retain their last setting
after power off/on. They are saved securely against power
outages. The parameter values marked with presetting corre
spond to the factory condition. Further information on the
working method of the diagnostic memory can be found in
section C.4.
The following parameters can be influenced:
Function no.
Diagnostic memory parameters
3480 Entries remanent with power ON
3480 Run/stop filter 1
3484 Run/stop filter 2
3484 Fault end filter
3484 Error number filter
3484 Module/channel filter
3485 Module number MN
3486 Channel number CN
3487 Error number FN
Tab.B/23: Overview  Diagnostic parameters
