Festo CPX - Idle Mode Channel X (Channel−Specific); Force Channel X (Channel−Specific)

B. Parameters and data of the CPX terminal
B−22
Festo P.BE−CPX−SYS−EN en 0902e
Module parameter: Idle mode channel x
Modules For modules with digital and analogue outputs (see manual for the module)
Function no. Access to these module parameters is made via protocol−specific functions (see
the CPX bus node description).
Description Only relevant for certain fieldbus protocols.
Idle mode channel x: Hold last state
Idle state (presetting)
Idle state channel x: Set output
Reset output (presetting)
Note With the aid of Idle mode parametrisation, the signal status which the outputs/
valves are to assume during a change into the Idle status can be determined
(see also section C.3.3).
Tab.B/21: Idle mode channel x (channel−specific)
Module parameter: Force channel x
Modules For modules with digital and analogue inputs and outputs (see manual for the
module)
Function no. Access to these module parameters is made via protocol−specific functions (see
the CPX bus node description).
Description Force mode of inputs channel x: blocked (presetting)
Force state
Force state of inputs channel x: Set signal
Reset signal (presetting)
Force mode of outputs channel x: blocked (presetting)
Force state
Force state of outputs channel x: Set signal
Reset signal (presetting)
Note The function Force permits the manipulation of signal states independent of
actual operating conditions (see also section C.3.1).
Tab.B/22: Force channel x (channel−specific)
For additional channel−specific module parameters as well as
detailed information, see the manual for the relevant module.
