2. Assembly
2−6
Festo P.BE−CPX−SYS−EN en 0902e
2.2 Assembling electric modules with plastic interlinking blocks
Caution
Inappropriate handling can result in damage to the mod
ules.
· Observe the handling specifications for electrostatically
sensitive devices.
· Discharge yourself before installing or removing sub−
assemblies to protect the sub−assemblies from static
discharges.
You can adapt the CPX terminal to your requirements by ad
ding or removing modules. The mechanical link between the
electric modules is made via tie rods in the interlinking
blocks. The length of the tie rod is determined
by the possible
number of interlinking blocks or electric modules.
Dismantle the CPX terminal before you add or remove inter
linking blocks. If you are using the additional fastenings of
type CPX−BG−RW−... for fastening onto a wall, it may be
necessary to loosen existing fastenings (see also Tab.2/4).
