B.2.1 Overview of the function numbers
Function no.
1)
CPX data and CPX parameters See
0 CPX operating mode (system data) Tab.B/48
0 CPX expansion (system data) Tab.B/49
0 Handheld (system data) Tab.B/50
0 Force mode (system data) Tab.B/51
0 System start (system data) Tab.B/52
1 Fail safe (system data) Tab.B/53
1 System idle mode (system data) Tab.B/54
2 Monitoring CPX terminal (system data) Tab.B/55
16 + 16m + 0 Module code (module data) Tab.B/59
16 + 16m + 13 Revision code (module data) Tab.B/60
784 + m * 4 + 0
784 + m * 4 + 1
784 + m * 4 + 2
784 + m * 4 + 3
Serial number (module data) Tab.B/62
1936 Status bits (system diagnostic data) Tab.B/39
1937 Module number and diagnostic status (system diagnostic data) Tab.B/40
1938 Error number (system diagnostic data) Tab.B/41
2008 + m * 4 + 0 Number of the first faulty channel (module diagnostic data) Tab.B/43
2008 + m * 4 + 1 Module error number (module diagnostic data) Tab.B/44
2008 + m * 4 + 2 Information 2 (module diagnostic data) Tab.B/45
2008 + m * 4 + 3 Information 3 (module diagnostic data) Tab.B/46
3480 Entries remanent with Power ON (diagnostic memory parameters) Tab.B/24
3480 Run/stop filter 1 (diagnostic memory parameters) Tab.B/25
1) m = module number (counting on the modules from left to right, beginning with 0)
