B.2 Description of the parameters and data
A distinction is made between the following parameters and
data:
Parameters
Description
System para
meters
Determine global system functions for the
complete CPX terminal, e.g.:
 Diagnostic monitoring
 System start etc.
Module para
meters
Determine module−specific and channel−spe
cific functions for the relevant module, e.g.:
 Input debounce time
 Signal extension times etc.
Diagnostic mem
ory parameters
Determine the working method of the diagnos
tic memory.
Tab.B/1: CPX parameters
Data
Description
System diagnostic
data
Global information on the system status
(e.g.common diagnostic message)
Module diagnostic
data
Information on fault finding (e.g. error number,
number of the first faulty channel etc.)
Diagnostic mem
ory data
Entries in the diagnostic memory (max. 40)
System data Information on global system settings
Module data Serial number, revision code and module code
of the modules used
Tab.B/2: CPX data
