Festo CPX - Fail−Safe Parametrisation Example for Binary Signals; Fail−Safe Parametrisation Example for Analogue Signals

C. General information on parametrisation
C−17
Festo P.BE−CPX−SYS−EN en 0902e
0
1 0 1 1 1 0 0
0 0 0 1 0 1 0 0
1
1 0 0 1 1 1 0
Fault mode
0 = Hold last state
1 = Fault state
Fault state
0 = Reset output
1 = Set output
1
0 0 1 0 1 1 0
1
2
3
1 Signal status before the fault
2 Module parameter
(channel−orientated)
3 Signal status after the fault
Fig.C/8: Fail−safe parametrisation  example for binary signals
0
1 0 1 1 1 0 0
222 500 500 500 333 321 100 200
100 321 444 230 700 604 0 333
Fault mode
0 = Hold last state
1 = Fault state
Fault state
100 500 444 500 333 321 0 333
1
2
3
1 Signal status before the fault
2 Module parameter
(channel−orientated)
3 Signal status after the fault
Fig.C/9: Fail−safe parametrisation  example for analogue signals
