Festo CPX - System Parameter Fail Safe; Module Parameters Fault Mode and Fault State

C. General information on parametrisation
C−16
Festo P.BE−CPX−SYS−EN en 0902e
System parameters Settings Description
Fail safe Reset outputs
(presetting)
Reset all outputs/valves
Hold last state Retain current signal status for all outputs/
valves
Assume Fault mode
value
Accept the signal status defined for the relevant
channel
Tab.C/4: System parameter Fail safe"
If Accept fault mode value" is activated, the signal states
defined by module parameter for the relevant channel will
become effective (see Fig.C/8).
Module parameters
Settings Description
Fault mode Hold last state Retain current signal status
Fault state
(presetting)
Accept the signal status defined by Fault state
Fault state
 Digital signal
Reset output
(presetting)
Reset output signal (output/valve)
Set output Set output signal (output/valve)
 Analogue signal Analogue value Value of the analogue signal
Tab.C/5: Module parameters Fault mode and Fault state
Mode of operation
The Fault mode" parameter is used to determine whether
the current signal status is to be retained or whether the
signal status defined by Fault state" is to be accepted.
