2.3 Assembling electric modules with metal interlinking blocks
Caution
Inappropriate handling can result in damage to the mod
ules.
· Observe the handling specifications for electrostatically
sensitive devices.
· Discharge yourself before installing or removing sub−
assemblies to protect the sub−assemblies from static
discharges.
You can adapt the CPX terminal to your requirements by ad
ding or removing modules. The mechanical link between the
electric modules is made via the threaded connectors be
tween the interlinking blocks.
Dismantle the CPX terminal before you
add or remove inter
linking blocks. If you are using the additional fastenings of
type CPX−M−BG−RW−... for fastening onto a wall, it may be
necessary to loosen existing fastenings (see also Tab.2/4).
