Festo CPX - System Parameter Force Mode; Module Parameters Force Mode and Force State

C. General information on parametrisation
C−12
Festo P.BE−CPX−SYS−EN en 0902e
By means of a system parameter, Force is enabled globally for
the CPX terminal or blocked.
System parameters
Settings Description
Force mode Disabled
(presetting)
Force is blocked for the complete CPX terminal
Enabled Force is enabled for the complete CPX terminal
Tab.C/2: System parameter Force mode
The signal status can be determined channel−orientated (out
put/valve/input) for each module (see Tab.C/3).
Module parameters
Settings Description
Force mode Disabled
(presetting)
Force is blocked for the channel
Force state Accept the signal status defined by Force state
Force state
 Digital signal
Reset signal (preset
ting)
Reset input/output signal
Set signal Set input/output signal
 Analogue signal Analogue value
(0 = presetting)
Value of the analogue signal
Tab.C/3: Module parameters Force mode" and Force state"
