Festo CPX - Dependency Diagram; Input Debouncing

C. General information on parametrisation
C−4
Festo P.BE−CPX−SYS−EN en 0902e
Dependency diagram
End
End
1
22
3
4
0
1
0
1
Start = debounce time started
End = debounce time completely expired
Sensor signal is unstable (shorter than debounce time)
Sensor signal is sufficiently stable (= debounce time)
Start
Start
Start
Start Start Start
1 Start and end (sequence) of the
debounce time
2 Debounce time has expired
3 Sensor signal
4 Logical CPX signal
Fig.C/1: Input debouncing
