Festo CPX - Influencing Input Signals

C. General information on parametrisation
C−10
Festo P.BE−CPX−SYS−EN en 0902e
Influencing input signals
1
Force
0
1
ForcechannelX
Forcemode
enable disable
disable
Input
Input signal
System parameters
Module parameters
1 Status LED of the respective input
Fig.C/5: Influencing input signals
Forcing an input does not modify the input signal itself and
cannot be observed at the relevant status LED. The logical
status of the input only changes internally and may be effec
tive programme technically.
Obtain further information on Idle mode, Fail safe and Forcing
from the following sections.
