Festo CPX - Module;Channel Filter; Module Number (MN)

B. Parameters and data of the CPX terminal
B−27
Festo P.BE−CPX−SYS−EN en 0902e
Diagnostic memory parameter: Module/channel filter
Function no. 3484
Description With this diagnostic memory filter, the registering of faults of other modules or
channels can be suppressed in order that faults in a particular module or chan
nel can be analysed.
Bit Bits 6, 7
Values
Bit 76
00
01
10
11
Module/channel filter
FN = error number
Description
Module/channel filter inactive (presetting)
Register only the FN of a module
Register only the FN of a channel
Reserved
[Module/channel filter]
[Inactive]
[Rec. FN of a mod.]
[Rec, FN of a ch.]
Note The numbers are determined by means of the diagnostic memory parameters
Module and channel numbers" (function nos. 3485...3486).
Tab.B/29: Module/channel filter
Diagnostic memory parameter: Module number (MN)
Function no. 3485
Description Module number for the diagnostic memory filter
Bit 0...7 (1 byte)
Values Module number (MN)
0...47 Module number (0 = presetting)
[Module number MN]
Note Is only effective if an appropriate diagnostic memory filter is active.
Tab.B/30: Module number (MN)
