B. Parameters and data of the CPX terminal
B−6
Festo P.BE−CPX−SYS−EN en 0902e
Function no.
1)
SeeCPX data and CPX parameters
3482 Number of entries in the diagnostic memory (diagnostic memory
data)
Tab.B/34
3483 Overrun (diagnostic memory data) Tab.B/35
3483 Status (diagnostic memory data) Tab.B/36
3484 Run/stop filter 2 (diagnostic memory parameters) Tab.B/26
3484 Fault end filter (diagnostic memory parameters) Tab.B/27
3484 Error number filter (diagnostic memory parameters) Tab.B/28
3484 Module/channel filter (diagnostic memory parameters) Tab.B/29
3485 Module number MN (diagnostic memory parameters) Tab.B/30
3486 Channel number KN (diagnostic memory parameters) Tab.B/31
3487 Error number FN (diagnostic memory parameters) Tab.B/32
3488 + n Diagnostic memory data (diagnostic memory data) Tab.B/37
4401 Monitoring (system parameters) Tab.B/4
4402 Fail safe (system parameters) Tab.B/5
4402 Force mode (system parameters) Tab.B/6
4402 System idle mode (system parameters) Tab.B/7
4402 System start (system parameters) Tab.B/8
4402 Analogue process value display (data format) Tab.B/9
4828 + m * 64 + 0 Monitoring the CPX module (module parameter) Tab.B/12
4828 + m * 64 + 1 Behaviour after short circuit/overload (module parameter) Tab.B/13
4828 + m * 64 + 1 Input debouncing time (module parameters) Tab.B/14
4828 + m * 64 + 1 Signal extension time (module parameters) Tab.B/15
4828 + m * 64 + 3 Data format for analogue value of inputs (module parameters) Tab.B/16
4828 + m * 64 + 3 Data format for analogue value of outputs (module parameters) Tab.B/17
1) m = module number (counting on the modules from left to right, beginning with 0)
