B. Parameters and data of the CPX terminal
B−7
Festo P.BE−CPX−SYS−EN en 0902e
Function no. Channel−specific module parameters See
−
1)
Signal extension channel x Tab.B/18
−
1)
Wire break monitoring, channel x Tab.B/19
−
2)
Fail safe channel x Tab.B/20
−
2)
Idle mode channel x Tab.B/21
−
2)
Forcing channel x Tab.B/22
1) Function number, see manual for CPX modules
2) Access is protocol−specific (see manual for CPX bus node)
Function no. Fieldbus−specific system data See
− Number of input bytes (Rx size)
1)
Tab.B/56
− Number of output bytes (Tx size)
1)
Tab.B/57
1) Only relevant with certain fieldbus protocols (see manual for CPX bus node)
