5. Diagnostics and error handling
5−22
Festo P.BE−CPX−SYS−EN en 0902e
Error numbers of error class 2
No. Eliminating faultsOperating statusHandheld display
20 [Fault in parametrizing si
gnal range]
Fault in parameterising
(signal range)
Check the parametrisation
undertaken and, if necessary,
undertake the parametrisa
tion again with the correct pa
rameters.
21 [Fault in parametrizing data
format]
Fault in parametrisation (data
format)
Check the parametrisation
undertaken and, if necessary,
undertake the parametrisa
tion again with the correct pa
rameters.
22 [Fault in parametrising
linear scaling]
Fault in parametrisation
(linear scaling)
Check the parametrisation
undertaken and, if necessary,
undertake the parametrisa
tion again with the correct pa
rameters.
23 [Fault in filter meas.value] Fault in parametrisation
(measured value smoothing)
Check the parametrisation
undertaken and, if necessary,
undertake the parametrisa
tion again with the correct
parameters.
24 [Fault in parametrizing
lower limit]
Fault in parametrisation
(lower limit)
Check the parametrisation
undertaken and, if necessary,
undertake the parametrisa
tion again with the correct
parameters.
25 [Fault in parametrizing
upper limit]
Fault in parametrisation
(upper limit)
Check the parametrisation
undertaken and, if necessary,
undertake the parametrisa
tion again with the correct
parameters.
26 [Fault in actuator supply] Fault in actuator supply Eliminate short circuit/over
load or check actuator supply,
if necessary, check connected
actuators
27 [Wrong device type moun
ted]
Missing or incorrect spare
part
Replace module or spare part
(e.g. air filter)
See manual for the relevant
module
