5. Diagnostics and error handling
5−26
Festo P.BE−CPX−SYS−EN en 0902e
Error numbers of error class 2
No. Eliminating faultsOperating statusHandheld display
72 ...
79
Reserved
80 [Function failure] Module−specific operative
malfunction
See manual for the relevant
module
81 ...
99
Reserved
100 [Configuration error] Fault in configuration or para
metrisation
Check configuration, correct if
necessary or repeat commis
sioning
101 [Execution error] Fault executing a positioning
job
Check and, if necessary,
correct the positioning job
102 [Record error] Fault executing a positioning
record
Check and, if necessary,
correct the positioning job
103 [Control error] Fault in control or in the para
meters of a positioning job
Check and, if necessary,
correct the positioning job
104 [System error A] Fault in the process control or
the system configuration
Check system configuration or
positioning job, I/O signals or
system status and correct as
necessary
105 [System error B] Fault in the peripherals; power
supply, operating pressure,
etc.
Check peripherals, power sup
ply and operating pressure
106 [Error in valve] Fault in valve or on axis string Check valve or lines for
damage, if necessary replace
107 [Controller error] Fault in the controller or drive
regulator
Check controller or drive regu
lator for damage, if necessary
replace
108 [Encoder error] Fault in measuring system or
on axis string
Check measuring system or li
nes for damage, if necessary
replace
109 [Error motor or power
stage]
Fault in the motor or power
section
Check motor or power section
for damage, if necessary
replace
