1. Overview of components
1−20
Festo P.BE−CPX−SYS−EN en 0902e
Interlinking blocks are available in plastic and metal designs
and with various alternative connections:
 M18 plug, 4−pin
 7/8" plug, 4−pin
 7/8" plug, 5−pin
 Push−pull plug, 5−pin
The pin allocation for all alternative connections is described
in Tab.3/4 and in the package insert for the interlinking
blocks with supply.
Section3.1.4 describes the criteria for selecting an
appropri
ate power supply unit, and calculation tables for designing
the electrical circuits.
