2. Assembly
2−30
Festo P.BE−CPX−SYS−EN en 0902e
1 Spacer discs on
the Midi/Maxi
pneumatic
interface
2 Spacer discs on
the right−hand
end plate
1
2
Fig.2/15: For wall mounting with Midi/Maxi pneumatics: remove the protective foil from
the adhesive surface and fit the spacer disc (rear view)
