4. Commissioning positioning systems
4−32
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
Project zero point Point related to the cylinder zero point. All positions occurring
in position registers and programs relate to the project zero
point.
Permitted: 0.00 ... 10000.00 [mm] or [°]
Lower software end
position
Defined end position on the side of the measuring system
zero point which is monitored by the SPC200 and which
must
not be overrun. The lower software end position refers
to the cylinder zero point and represents the lower limit of
the positioning range.
Permitted: 0.00 ... 10000.00 [mm] or [°]
Upper software end
position
Defined end position on the side of the measuring system
zero point which is monitored by the SPC200 and which
must not be overrun. The upper software end position refers
to the cylinder zero point and represents the upper limit of
the positioning range.
Permitted: 0.0 ... 10000.00 [mm] or [°]
If both software end positions are set to 0", their function
will be suppressed.
Positioning tolerance This parameter states the repetition precision at which
a
positioning movement is to be carried out.
Permitted: 0.10 ... 10.0 [mm] or [°]
