Fiat Ducato - Manual Opening of the Second Swing Door; Electrical Closure from Inside

F0N0130m
fig. 115
F0N0129m
fig. 114
F0N0132m
fig. 117
F0N0131m
fig. 116
Electrical closure from inside fig. 117
Close the two rear swing doors (first the left, then the
right) and press button D located in the window control
panel.
Manual opening of the second swing door,
fig. 116
Pull handle C in the arrowed direction.
The rear swing doors are equipped with a spring loaded
system that locks them at an approx. angle of 90 degrees
during opening.
