F0N0231m
fig. 35
F0N0020m
fig. 36
HEAD RESTRAINTS
FRONT fig. 36
On certain versions the head restraints are adjustable in
height and they lock automatically in the required position.
Adjustment
❒
upwards adjustment: lift the head restraint until it locks;
❒
downward adjustment: press the button A and lower
the head restraint.
To extract the front head restraints press the buttons
A and B on both sides simultaneously and release them
upwards.
– lift the base of the seat forward;
– move the seat upright;
– from the upright position, operate the levers E and
F – fig. 35, turning them upward;
– raise the bench from the floor and remove it.
When refitting the bench, ensure it is cor-
rectly locked to the floor guides.
WARNING
037-122 DUCATO LUM EN 11-02-2010 14:26 Pagina 45
