FUSE TABLE
Fuse box on dashboard fig. 200
USERS FUSE AMPERES
Right dipped beam headlight F12 7.5
Left dipped beam headlight, headlight alignment corrector F13 7.5
Engine compartment control unit relay, instrument panel control unit relay (+key) F31 7.5
Minibus interior lights (emergency) F32 10
Rear current socket F33 15
Absent F34 –
Reversing lights, Servotronic control unit, water in diesel filter sensor, (+key) F35 7.5
Central locking control unit (+battery) F36 15
Brake light control (main), third brake light, instrument panel (+key) F37 7.5
Instrument panel control unit relay (+battery) F38 10
EOBD socket, Radio, A/C control, Alarm, Tachograph,
Webasto timer (+battery) F39 10
Left heated rear window, driver side mirror demister F40 15
Right heated rear window, passenger side mirror demister F41 15
ABS, ASR, ESP, Brake light control (secondary) (+key) F42 7.5
Windscreen washer (+key) F43 30
Cigar lighter, Front power point F44 20
Controls on driver’s side door, Controls on passenger side door F45 7.5
Absent F46 –
