FUEL RESERVE (amber)
This warning light comes on when the ignition key is turned
to MAR, but it should go off after a few seconds.
The warning light turns on when about 10 to 12 litres of
fuel are left in the tank (depending on the version).
IMPORTANT The warning light will blink to indicate a sys-
tem failure. If this is the case, contact a Fiat Dealership to
have the system checked.
Warning light F indicates failure of warn-
ing light
¬
. This condition is indicated by
intermittent blinking of warning light
“ for longer
than 4 seconds. In this case, warning light
¬
may
not indicate fault to the system. Contact a Fiat
Dealership immediately to have the system
checked.
WARNING
ç
ABS SYSTEM FAILURE (amber)
When the key is turned to the MAR position the warning
light comes on but should go out after a few seconds.
The warning light will light up when the system is either
not working or not available. Under these circumstances
the braking system will work as normal without the extra
performance offered by the ABS system. Drive carefully
and contact a Fiat Dealership as soon as possible.
On some versions the display shows the dedicated message.
>
GLOW PLUG WARMING
(Multijet versions – amber)
GLOW PLUG HEATING FAILURE
(Multijet versions – amber)
Glow plugs
This warning light comes on when the key is turned to
MAR. It will go out as soon as the heater plugs have
reached a preset temperature. Start the engine as soon as
the warning light goes out.
IMPORTANT At high ambient temperatures the warn-
ing light stays on for an extremely short time.
Glow plug warming failure
The warning light flashes if there is a fault in the preheat-
ing system. Contact a Fiat Dealershipa Fiat Dealership as
soon as possible.
On some versions the display shows the dedicated message.
m
