WARNING LIGHTS AND MESSAGES
GENERAL WARNINGS
Lighting of a warning light is associated to a specific mes-
sage and/or buzzer when applicable. These indications are
brief and precautionary and as such must not be consid-
ered as exhaustive and/or alternative to the information
contained in the Owner Handbook, which you are rec-
ommended to read carefully in all cases. Always refer to
the information in this chapter in the event of a failure
indication.
IMPORTANT Failure indications displayed are divided in-
to two categories: very serious and less serious failures.
Serious faults have a repeated signals cycle for a long time.
Less serious faults have a signal cycle for a shorter time.
Press MODE to stop the warning cycle in both cases.
The warning light on the instrument panel will stay on
until the cause of the fault is eliminated.
For messages relevant to the versions equipped with Du-
alogic gearbox, see the attached Supplement.
155
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
WARNING LIGHTS AND MESSAGES
If the warning light x turns on when trav-
elling (on certain versions together with
the message on the display) stop the car imme-
diately and contact Fiat Dealership.
WARNING
LOW BRAKE FLUID LEVEL (red)
HANDBRAKE ON (red)
When the key is turned to the MAR position the warn-
ing light comes on but should go out after a few seconds.
Low brake fluid level
The warning light comes on when the level of the brake
fluid in the reservoir falls below the minimum level due to
a possible leak in the circuit.
On some versions the display shows the dedicated message.
x
Handbrake on
The warning light turns on when the handbrake is on.
On certain versions, if the vehicle is moving the buzzer will
also sound.
IMPORTANT If the warning light turns on when travel-
ling, check that the handbrake is not engaged.
