fig. 16
DIGITAL DISPLAY
STANDARD SCREEN fig. 16
The standard screen shows the following information:
A Headlamp alignment position (only with dipped head-
lamps on);
B Time (always displayed, even with the key extracted
and the front doors closed);
C Odometer (distance covered in kilometres or miles)
and TRIP data.
NOTE With key removed (when opening one of the front
doors) the display turns on and shows the time and km or
miles covered for a few seconds.
The symbols are gradually turned off as the oil level drops.
Four or 5 symbols light up to indicate a sufficient level of
oil in the sump. If the fifth symbol is not lit, this does not
indicate a fault or that insufficient oil is present in the sump.
If the oil level is lower than the minimum required value,
the display shows a dedicated message indicating minimum
engine oil level and the need for a top-up.
IMPORTANT To find out the correct oil quantity, always
check using the dipstick (see paragraph “Checking levels”
in the section “Maintenance and care”).
After a few seconds, the symbol display indicating the
amount of engine oil disappears and:
❒ When the next scheduled servicing is near, the time
to the next service is displayed and the warning light
õ lights up on the instrument panel. When the service
date is reached, the display shows a dedicated message;
❒ then, if it is nearly time to change the engine oil, the time
to the next oil change is shown on the top row of the
display. When the service interval has expired a dedi-
cated warning will be shown on the display.
18
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
001-036 DUCATO LUM EN 11-02-2010 13:53 Pagina 18
