F0N0063m
fig. 120
BONNET
OPENING
Proceed as follows:
❒
open the driver’s door to gain access to the bonnet
release;
❒
pull the lever fig. 120 in the direction of the arrow;
❒
pull the lever A-fig. 121 as shown in the figure;
❒
lift the bonnet and, at the same time, release the bon-
net stay fig. 122 from its locking device D, then insert
the end C-fig. 123 of the bonnet stay into the housing E.
IMPORTANT Before opening the bonnet, check that wind-
screen wiper arms are not lifted from the windscreen.
IMPORTANT With the ignition key in the STOP position
or extracted, the electric windows remain activated for
about 3 minutes and are then deactivated immediately
when one of the doors is opened.
104
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
Incorrect use of the electric windows may
be dangerous. Before and during opera-
tion, always check that no-one is exposed to the
risk of being injured either directly by the moving
window or through objects getting caught and be-
ing dragged by it. When leaving the vehicle, always
remove the key from the ignition to avoid the risk
of injury to anyone remaining in the car due to ac-
cidental operation of the electric windows.
WARNING
Front passenger side door
A dedicated switch for operating the window is located
on the inner armrest of the passenger side front door.
037-122 DUCATO LUM EN 11-02-2010 14:27 Pagina 104
