Fiat Ducato - Fuse Location; Fuse Box on the Dashboard; Engine Compartment Control Unit; Right Central Pillar Optional Control Unit

F0N0095m
fig. 199
F0N0096m
fig. 200
Right central pillar optional control unit
(for versions/markets, where provided)
To gain access to the fuse box fig. 204, remove the pro-
tective cover fig. 203.
FUSE LOCATION
The vehicle fuses are grouped in three control units lo-
cated on the dashboard, passenger compartment right pil-
lar and engine compartment.
Fuse box on the dashboard
To gain access to the fuse box fig. 200 on the dashboard,
loosen the fastening screws A-fig. 199 and remove the cov-
er.
Engine compartment control unit
To gain access to the fuse box, fig. 202, remove the pro-
tective cover fig. 201.
