Fiat Ducato - Defrosting;Demisting; Electric Folding; Folding

F0N0834m
fig. 40
F0N0159m
fig. 41
IMPORTANT If the mirror is folded back manually, it
should be returned to its original position manually; if the
mirror is folded back electrically, it should be returned
to its original position electrically.
Defrosting/demisting
(for versions/markets where provided)
The mirrors are fitted with resistors that are activated
when the heated rear windscreen is turned on (by press-
ing button
(
).
IMPORTANT This function is timed and it will turn off au-
tomatically a few minutes later.
Folding
When required (for example when the mirror causes dif-
ficulty in narrow spaces) it is possible to fold the mirror
moving it from position 1 – fig. 40 to position 2.
48
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
When driving the mirrors should always be
in position 1 – fig. 40.
Electric folding
(for versions/markets where provided)
Adjust the rocker switch A – fig. 41, by pressing on side 1
to place the mirror in the open position, on side 2 to place
the mirror in the closed position.
As the driver’s wing mirror is curved, it may
slightly alter the perception of distance.
WARNING
037-122 DUCATO LUM EN 11-02-2010 14:26 Pagina 48
