SEAT BASE PLASTIC COVERS fig. 30e
(for versions/markets where provided)
The Front cover A can be opened by operating the release
handle B on the upper part.
This gives access to the under-seat compartment (see “un-
der-seat compartment” paragraph).
To make it easier to open the front cover and gain ac-
cess to the compartment, the seat must be as far back as
possible.
To allow removal of the front cover, it must be turned as
far forward as possible and withdrawn from the hooks on
the lower side by pulling toward the front of the vehicle.
COMPARTMENT UNDER THE SEAT
(for versions/markets where provided)
A compartment A – fig. 30d is present under the seat that
can be easily removed by withdrawing the hooks on the
support base.
