Fiat Ducato - S.b.r. System; Seat Belt with Reel for Front Central Place on Bench Seat

S.B.R. SYSTEM
The vehicle is fitted with a Seat Belt Reminder system
(S.B.R.), consisting of a buzzer and a flashing warning light
<
on the instrument panel which warns the driver that the
seat belt must be fastened.
The buzzer can be deactivated (until the next engine stop)
as follows:
❒ fasten the driver’s seat belt;
❒ turn the ignition key to MAR;
❒ wait for over 20 seconds and then release one of the
seat belts.
For permanent deactivation, contact the Fiat Dealership.
With digital display, the S.B.R. system can only be reset
at Fiat Dealership.
With multifunction display, the S.B.R. system can also be
reset through the set-up menu.
F0N0070m
fig. 132
F0N0156m
fig. 133
Seat belt with reel for front central place
on bench seat
The two-seater front bench is equipped with an on-board
seat belt (reel on seat) with three anchorage points for the
central place.
Correct regulation is obtained when the belt passes ap-
proximately half way between the shoulder and the neck.
124
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
After adjustment, always check that the
cursor to which the ring is fastened is
locked in one of the set positions. Push downwards
to enable the locking device to click if the grip has
not been released in one of the possible positions.
WARNING
